Adder Technology AVX1008 KVM Switch
USB keyboard and mouse control
Any USB style keyboard and mouse (PC, Mac or Sun) can be used to control the ADDERView CATx 1000 switch. Full keyboard re-mapping is supported to ensure seamless cross platform functionality Faultless video quality
The ADDERView CATx series provides exceptionally high video performance to local and remote users alike, supporting up to 1920 x 1200 resolutions with DDC emulation which is further enhanced by DC balancing to ensure full and true colour True multi-platform support
The ADDERView CATx 1000 supports any computer platforms with PS/2, USB and Sun keyboard and mouse interfaces. Country code reporting, DDC and continuous keyboard and mouse emulation ensure faultless operation Easy cascade
Expand simply by using just CATx cable to link units. The ADDERView automatically detects cascade connections to support up to 256 computers Optional CD quality audio
ADDERView CATx 1000 switches support CD quality 44.1kHz digital stereo audio when optional audio enabled CAM modules are used Options port
Integration with RS232 controlled power switches to provide a complete hard reboot function
Flash upgrade
Sync with other CATx 1000 switches for multi-video applications
Upload/download CATx 1000 user and host information
Remote control Integrated CATx extender
The ADDERView CATx 1000 can be controlled by a user from up to 300m away over CATx cable using an ADDERLink X200 or X100 receiver and the integrated CATx extender Computer Access Modules
Flash upgradeable CAMs are available for PS/2, USB and Sun keyboard and mouse support with optional audio Standard Transmission Distance
KVM communication from switch to target devices (e.g. Servers) can be up to 33 feet (10m) maximum Rack mount / rack drawers
One or two CATx 1000 switches can be mounted in 1U of rack height giving a maximum of 32 ports per U. The small size also makes the units ideal for mounting behind KVM rack drawers User access control
Up to 16 different user profiles can be created and access rights for each user can be defined Embedded KVM option
CATx 1000 technology is available in for embedding within other equipment such as rack drawers and industrial equipment
AVX1008 Features
- USB Keyboard and Mouse Control
- Faultless Video Quality
- True Multi-Platform Support
- Easy Cascade
- Integrated CATX Extender
- Audio Connectivity
- Features PS2 Connection
Request a Quote
Product Type
Format
Manufacturer
Country Of Manufacture
United Kingdom
Case Material
Robust Metal Case
Certifications
CE, RoHS compliant
Custom Options Products
Interface,Processor,Memory,Storage,Connections,Operating System
Additional Accessories
RMK4S: Single rack brackets RMK4D: Dual rack brackets CAB-9M/9F-2M Serial option cable
Case Material
Robust Metal Case
Computer Connections
Video: DVI-I, Keyboard/Mouse: USB type B, Audio: 3.5mm stereo jack
Computer Connections At Switch
RJ45
Hardware Compatibility
Video, mouse, keyboard and optional audio support for PC, Sun, Mac, RS/6000, Alpha and SGI computers using PS/2, USB or Sun flash upgradable Computer Access Modules (CAMs).
KVM Computer Connections
Video: HDD15, Keyboard/Mouse: choice of USB, PS/2 and Sun MiniDin8 Audio (optional): 3.5mm stereo jack
KVM Connections
Remote KVM console: RJ45, Options (flash upgrade, sync with other CATx1000 and RS232 triggered power switches): DB9 female
Local KVM Console Connection
Video: HDD15, Keyboard/Mouse: USB type A, Audio: 3.5mm stereo jack
No. Of Ports
4
OS Compatibility
All known software and operating systems including Windows (all), DOS, Linux, Unix,BSD, Sun OS, Solaris, Mac OS, NetWare etc.
Physical Design
1U high 198mm / 7.92"(w), 44mm / 1.76"(h), 120mm / 4.8"(d), 750g / 1.65 lbs. 1 per 1U or 2 per 1U rack mount kits available
Power
100-240VAC 50/60Hz input to power adapter, 5VDC 2A output from power adapter. 2.5mm DC jack, power adapter included
Rackmount Options
RMK3: 19 inch Rackmount kit (234mm wide, 1U products)
Software Compatibility
Operates with all known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, all Sun OS, all Mac OS, NetWare etc.
Video Modes
Analog: up to 1920 x 1200 x 60Hz, Single link digital: up to 1600 x 1200 x 60Hz, Dual link digital: up to 2560 x 1600 x 60Hz
Operating Temperature
OPERATING: 0C to +40C
Ordering Info
AVX1008-XX: 8 port version AVX1016-XX: 16 port version XX= Mains Lead Country Code: UK = United Kingdom US = United States EURO = Europe AUS = Australia
The Adder Technology AVX1008 KVM Switch is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the AVX1008 is commonly used:
These examples highlight the versatility of the Adder Technology AVX1008 KVM Switch across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this KVM, KVM Switch fits your specific needs, please contact us.
The Adder Technology AVX1008 KVM Switch comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Adder Technology AVX1008 KVM Switch, must be presented to RUGGED in the United Kingdom.
For more information about the Adder Technology AVX1008 KVM Switch or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Adder Technology AVX1008 KVM Switch?
If you have any questions about the Adder Technology AVX1008 please get in touch today, our team of technical experts are ready to assist you.
