iBASE FWA8108 Network Appliance
Networking,rugged,FWA8108,iBASE
FWA8108 Features
- Supports 3rd Generation Intel Core I7/I5/I3 / Xeon Processors
- 8X PCI-E GBE Ports
- 4X DDR3 Dimms, Max. 32 Gb
- 3X System Smart Fans
- 1X Cf Socket, 1X Mini PCI-E Slot (MSATA Compatible)
- Iamt 8.0
Request a Quote
Product Type
Format
Processor
Manufacturer
Country Of Manufacture
Taiwan
Certifications
CE, RoHS compliant
Dimensions
440 mm (W) x 411.5 mm (D) x 44 mm (H) 17.3"(W) x 16.2"(D) x 1.73"(H)
GbE Ports
8
Humidity
5%-90% Humidity Resistant
CPU
LGA1155 for 3rd Generation Intel Core i7/i5/i3 / Xeon processors
Expansion Slots
1x Mini PCI-E (mSATA compatible) socket 2 slots opening on rear panel
LAN
1x Intel 82579LM GbE PHY w/ iAMT 8.0 support 7x Intel 82583V GbE, w/o Bypass
LED
Power / Status
Memory
4x DDR3 DIMMs Max. 32GB, up to 1600 MHz ECC or non-ECC (depending on CPU)
No. Of Ports
8 GbE Ports
Ports filter
8
Power Supply
Full range 300W ATX
Serial I/O
1x RJ45 console, COM2 pin header
Storage
2.5" / 3.5" HDD drive bay support 1x CF socket
TPM
TPM 1.2
USB
2x USB 3.0 ports on front panel
VGA
Pin header
Operating Temperature
0C~ 45C (32CF~113CF)
Ordering Info
MB967 LGA1155 for 3rd Generation Core i7/i5/i3 / Xeonï¾®, C216 PCH, 1x Intel GbE 82579LM + 7x Intel GbE 82583V, LAN 5/6 & 7/8 Bypass, SATA connector, Mini PCI-E, CF & PCI-E expansion VGA4 VGA cable USB2-7 Dual port USB 2.0 cable, 300mm IP331 1-to-1 PCI-E 8x riser card IP332 PCI-E 8x adapter card IP333 2-to-2 PCI-E 8x riser card
Processor
Intel
Storage Temperature
-20C ~ 70C (-4CF~158CF)
The iBASE FWA8108 Network Appliance is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the FWA8108 is commonly used:
These examples highlight the versatility of the iBASE FWA8108 Network Appliance across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Network Appliance fits your specific needs, please contact us.
The iBASE FWA8108 Network Appliance comes with a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE FWA8108 Network Appliance, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE FWA8108 Network Appliance or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE FWA8108 Network Appliance?
If you have any questions about the iBASE FWA8108 please get in touch today, our team of technical experts are ready to assist you.
Alternative Products
Discover a range of alternatives that offer comparable features and quality to the product you’re viewing.
Our selection of similar items provides diverse options, allowing you to explore different designs, functionalities, and styles tailored to your preferences. Each product has been carefully chosen to ensure it meets the high standards you expect, enabling you to make a well-informed decision based on your unique requirements.
Browse through our related products and find the perfect match that complements your choice seamlessly.
FWA8208
FWA8800
- AMD EPYCâ„¢ Embedded 3000 Series
- 4x DDR4 DIMMs up to 2667MHz; Max. 64GB UDIMM(ECC or non-ECC) or 128GB RDIMM
- 2x NIC module slots, Max. 16 GbE Ports
MB967
- Supports 3rd Generation Intel Core I7/I5/I3 / Xeon Processors
- 8X PCI-E GBE Ports
- 4X DDR3 Dimm, Max. 32 Gb
FWA8308
- Supports 4th Generation Intel Core I7/I5/I3 / Xeon Processors
- Advanced LAN Bypass
- 8X PCI-E GBE Ports
