iBASE MB980 Industrial Motherboard
The MB980 in ATX form factor supports the 4th Generation Intel Core i7/i5/i3 processors that are manufactured on industry-leading 22nm process technology with 3D Tri-Gate transistors.
MB980 Features
- Original OEM Module
- Rohs Compliant, CE
- 12X PCI, 2X ISA
- Led Power Indicators For +5V, -5V, +12V, -12V, 3.3V, +5Vsb
- Size: 264.2mm X 311.2mm (10.4"X 12.3")
Request a Quote
Product Type
Format
Processor
Manufacturer
Country Of Manufacture
Taiwan
Certifications
RoHS Compliant, CE
Dimensions
305mm x 244mm (12" x 9.6")
Audio
Intel Q87 PCH built-in HD audio + Realtek ALC892 codec
BIOS
AMI
Display Interface
Supports DVI-I, DVI-D and DisplayPort
Expansion Slots
4x PCI, 1xPCI-E(x16), 1xPCI-E(x4), 1xPCI-E(x1)
Form Factor FILTER
ATX
H/W Monitor
Yes
I/O Chipset
Fintek F81866AD-I 1x RS232/422/485 (jumperless selection) 5x RS232, 6x SATAIII
LAN Connector
RJ-45 on board
LAN Controller
Intel I217LM Gigabit LAN PHY Intel I211AT PCI-E Gigabit LAN
Others
Digital I/O (4-in/4-out), EuP/ErP supporting, RAID, TPM (1.2), iAMT (9.0), iSMART
SSD
N/A
System Memory
4x DDR3 DIMM, Max. 32GB (Non-ECC)
System Speed
up to 3.4GHz
USB
2 ports on board, 8 ports via pin-header (USB 2.0) 4 ports on board (USB 3.0)
VGA Controller
4th Generation Intel Core i7/i5/i3/ Pentium processor integrated
VGA Memory
Max. Shared memory 1024MB
Watchdog Timer
256 levels
Form Factor
ATX
Humidity
90% Humidity Resistant (non-condensing @ 60C)
Operating Temperature
0C~60C (32CF~140CF)
Ordering Info
MB980VF LGA1150 Q87 ATX Motherboard w/ DVI-I, DVI-D, DisplayPort, dual Gigabit LAN, RAID, EuP/ErP compliant, iAMT (9.0), vPro, iSMART
Processor
Intel
Storage Temperature
-20C~80C (-4CF~176CF)
The iBASE MB980 Industrial Motherboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the MB980 is commonly used:
Industrial and Manufacturing, Medical and Healthcare, Pharmaceutical
These examples highlight the versatility of the iBASE MB980 Industrial Motherboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Industrial Motherboard, Motherboard, Rugged Motherboard fits your specific needs, please contact us.
The iBASE MB980 Industrial Motherboard comes with a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE MB980 Industrial Motherboard, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE MB980 Industrial Motherboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
