iBASE MI981 Industrial Motherboard
The MI981 Mini-ITX motherboard adopting the Intel Q87 chipset and the new generation of Intel Core processors. It is designed to provide high performance and flexibility for functional expansions, and is ideal for applications in industrial control, factory automation, communications and gaming industries.
MI981 Features
- Original OEM Module
- Rohs Compliant, CE
- 3X PCI-E Gigabit Lan
- DVI-I, Displayport & 24-Bit Dual Channel Lvds
- Watchdog Timer, Digital I/O, ISMART 3.1, Raid
- 5X SATA Iii, 4X USB 3.0, 8X USB 2.0, 6 X Com, 1X Msata
- 1X PCI-E(X16), 2 X Mini PCI-E
- 1X Sim Card Slot
Request a Quote
Product Type
Format
Processor
Manufacturer
Country Of Manufacture
Taiwan
Certifications
RoHS Compliant, CE
Dimensions
170mm x 170mm (6.7" x 6.7")
Audio
Intel Q87 PCH built-in HD audio controller + Realtek ALC892 w/ 7.1 channels
BIOS
AMI BIOS
Display Interface
Supports VGA, DVI-D, LVDS and DisplayPort
Expansion Slots
1x PCI-E(16x) slot 2x Mini PCI-E (1x full-size, 1x half-size)
Form Factor FILTER
Mini-ITX
H/W Monitor
Yes
I/O Chipset
Fintek F81866AD-I 1x RS-232/422/485 (Jumperless selection) 5x RS232, 4x SATA III
LAN Connector
2x RJ45 on board
LAN Controller
Intel I217LM Gigabit LAN PHY Intel I211AT PCI-E Gigabit LAN( as 2nd LAN)
Others
Digital I/O [4-in/4-out], TPM 1.2, iAMT9.1, iSMART3.0
SSD
1x mSATA
System Memory
2x DDR3-1600 SO-DIMM, Max 16GB (Non-ECC)
System Speed
2.7GHz
USB
6 ports USB3.0 on board 6 ports USB2.0 via pin header
VGA Controller
4th Generation Intel Core DT i7/i5/i3 processors integrated graphics
VGA Memory
Max. Shared memory 1024MB
Watchdog Timer
256 levels
Expansion
PCI-E
Form Factor
Mini-ITX
Humidity
90% Humidity Resistant (non-condensing @ 60C)
Operating Temperature
0C~60C (32CF~140CF)
Ordering Info
MI981AF LGA1150 Q87 Mini-ITX motherboard w/ VGA, DVI-D, LVDS, DisplayPort, dual Gigabit LAN, TPM 1.2, iAMT9.1, iSMART3.0
Processor
Intel
Storage Temperature
-20C~80C (-4CF~176CF)
The iBASE MI981 Industrial Motherboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the MI981 is commonly used:
Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence
These examples highlight the versatility of the iBASE MI981 Industrial Motherboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Industrial Motherboard, Motherboard, Rugged Motherboard fits your specific needs, please contact us.
The iBASE MI981 Industrial Motherboard comes with a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE MI981 Industrial Motherboard, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE MI981 Industrial Motherboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
