iKey PM-18-HP Panel Mount Rugged Keyboard

The PM-18-HP provides a full numeric keypad that is easily integrated into any system. The secondary legend can be accessed by pressing the NumLock key. The PM-18-HP further increases its versatility with the two-button Hula Point industrial pointing device. It is also possible to cascade a secondary keyboard if needed.

PM-18-HP Features

  • Integrated Pointing Device
  • Numlock Key For Secondary Keyboard
  • USB, PS2 and AT/Serial Configurations Available
  • Customisation Available On Request
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

No Backlight

Case Material

No Case

Certifications

IP Rated, NEMA 4X UL60950, FCC Part 15 Class B

Custom Options Products

Cable Type,Cable Length,Interface

Dimensions

5.85" x 8.51" x 0.31" (w-h-d) 148.6mm x 216.2mm x 7.9mm SCREWS: 0.50" (12.7mm)

Extended Warranty

Available On Request

Humidity

100% Humidity Resistant (when properly installed)

Cable

LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2 or AT/serial Cable (providing separate keyboard and mouse connections)

Compatibility

PS/2 KEYBOARD/HULAPOINT: All Windows Operating Systems USB KEYBOARD/HULAPOINT: All Windows and Macintosh OS

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 4.74 oz. +/- 1.06 oz. (135g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

18

Pointing Device

HulaPoint

Power

PS/2 and USB KEYBOARD: 40mA@5V (from Keyboard port) PS/2 and USB POINTER: 10mA@5V (from Mouse port)

Product Weight

2.00 lbs +/- 0.10 lbs (0.91 kg +/- 0.05 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

135g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +65C (-40F to +149F) OPERATING: -0C to +60C (+32F to +140F)

The iKey PM-18-HP Panel Mount Rugged Keyboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the PM-18-HP is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence

These examples highlight the versatility of the iKey PM-18-HP Panel Mount Rugged Keyboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The iKey PM-18-HP Panel Mount Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey PM-18-HP Panel Mount Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey PM-18-HP Panel Mount Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey PM-18-HP Panel Mount Rugged Keyboard or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iKey PM-18-HP or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.

  • Alternative Products

    Discover a range of alternatives that offer comparable features and quality to the product you’re viewing.

    Our selection of similar items provides diverse options, allowing you to explore different designs, functionalities, and styles tailored to your preferences. Each product has been carefully chosen to ensure it meets the high standards you expect, enabling you to make a well-informed decision based on your unique requirements.

    Browse through our related products and find the perfect match that complements your choice seamlessly.

    • Integrated Pointing Device
    • Slim, Compact Design
    • Ms Windows Function Keys
    • Non-Incendive For Hazardous Environments
    • Bluetooth - Compatible Version 2.0
    • Up To 30-Foot Range
    • 72-Key Functionality
    • 8 Function Keys
    • Lightweight ABS Polycarbonate Case
    iKey DP-72 Rugged Keyboard
    • Cleanable, Liquid Proof Design
    • Integrated Pointing Device
    • ABS Polycarbonate Frame
  • Having trouble finding what you're looking for?


    Selecting the right product for your specific application and environment can be quite challenging. At Rugged, our team of experts is on hand to assist you in making the best choice. Whether you have questions about product specifications or require guidance through our range of solutions, we’re here to help.

    With our extensive industry knowledge and commitment to quality, we can ensure you find the ideal solution tailored to your needs.

    Contact Us
  • Frequently Asked Questions

    • If you are unsure which product is best suited to your requirements, you can contact us directly for expert guidance. Share details such as your use case, environment, compatibility needs, and budget, and we will help you select the most appropriate solution.

    • FB Peripherals offers free technical support for the lifetime of products you purchase. This includes help with setup, troubleshooting, and integration. Support is available online or directly from the technical team

    Rugged keyboards are designed to endure harsh environments and intensive usage, typically featuring robust materials and sealed designs to resist dust, water, and mechanical wear. The rugged keyboard lifespan often extends beyond 10 million key presses, significantly outperforming standard keyboards. Factors influencing longevity include build quality, environmental conditions, and maintenance practices. FB Peripherals offers a range of rugged keyboards engineered to provide reliable, long-term performance in mission-critical applications, ensuring minimal downtime and sustained operational efficiency in challenging industrial settings.

    Yes, rugged keyboards can be customised to meet specific operational requirements, especially for use in harsh or mission-critical environments. Customisation options often include varying key layouts, specialised key switches, enhanced durability features such as waterproofing and dust resistance, as well as customised materials and finishes tailored to environmental challenges. FB Peripherals is a trusted supplier offering a comprehensive range of custom rugged keyboards designed for industrial and outdoor applications, ensuring reliability and performance in tough conditions.

    Rugged keyboards are designed to provide reliable performance in harsh environments, making them ideal for industrial and mission-critical applications. Most rugged keyboards are compatible with both Windows and Linux operating systems, ensuring seamless integration into various system architectures. This versatility is crucial for users requiring durable input devices that maintain functionality under demanding conditions. At FB Peripherals, we specialise in supplying rugged keyboards that support multiple platforms, offering durable and user-friendly options for your industrial computing needs.

    Rugged keyboards designed for industrial and harsh environments are typically dustproof, ensuring reliable performance even in dusty or debris-laden settings. These keyboards are sealed with specialised materials and coatings to prevent dust ingress, which can cause malfunctions or reduce lifespan in standard peripherals. At FB Peripherals, dustproof rugged keyboards are engineered to meet strict IP ratings, providing superior protection and durability required for mission-critical applications. For a robust solution that guarantees consistent operation under challenging conditions, explore our range of rugged keyboards, trusted by industries worldwide.

    Medical rugged keyboards are specifically designed to withstand the demanding conditions of healthcare environments. They offer robust protection against liquids, dust, and frequent cleaning with disinfectants, which is essential for maintaining hygiene and preventing contamination. These keyboards also ensure reliable operation in critical medical applications where durability and responsiveness are paramount. FB Peripherals provides a range of medical rugged keyboards that combine durability with compliance to healthcare standards, making them a trusted choice for hospitals, clinics, and laboratories.

    Yes, many rugged keyboards support programmable keys, offering customised functionality essential for mission-critical applications. Programmable rugged keyboards allow users to assign specific functions or macros to dedicated keys, enhancing efficiency and operational control in harsh environments. These keyboards are designed to maintain reliability and durability, even under extreme conditions. FB Peripherals provides a selection of programmable rugged keyboards tailored to industry needs, ensuring seamless integration and robust performance for industrial and outdoor use.

    Yes, rugged keyboards can be used in cleanrooms, provided they are specifically designed to meet stringent hygiene and contamination control standards. Cleanroom rugged keyboards from trusted suppliers like FB Peripherals are built with sealed, flat surfaces that resist dust, liquids, and microbes, ensuring minimal particle generation. These keyboards use materials and construction methods that withstand frequent cleaning with industrial-grade disinfectants without compromising functionality. For mission-critical applications in pharmaceutical, semiconductor, and laboratory environments, cleanroom rugged keyboards from FB Peripherals offer reliability and durability essential to maintaining cleanroom integrity. Explore their full range at FB Peripherals rugged keyboards.

    Yes, rugged keyboards can be effectively used in marine environments. Designed to withstand harsh conditions such as saltwater exposure, high humidity, and extreme temperatures, marine rugged keyboards offer reliable performance and durability. These keyboards feature robust construction with sealed, corrosion-resistant materials, ensuring longevity even in challenging maritime settings. For mission-critical applications, selecting a high-quality marine rugged keyboard is essential. FB Peripherals specialises in supplying industrial-grade rugged keyboards tailored to marine environments, providing dependable input solutions for vessels and offshore installations. Explore the full range of rugged keyboards suitable for marine use.
