RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display

The RD-0571-ISC 5.7″ IP66 Stainless Chassis LCD Display has a host of features including OSD With Multi-Language Support ,Wall Mount VESA Compliant ( 75 x 75 mm),Integrated Stereo Speakers to name a few. Designed and built to survive harsh conditions and are perfectly suited for Aerospace , Commercial , Defence , Industrial Consoles , Marine Consoles , Medical Systems , Military , OEM , Radar Applications , System Integrators and other demanding applications. The typical lifetime of an RD-0571-ISC 5.7″ IP66 Stainless Chassis LCD Display is approximately 35,000 hours (typ).

RD-0571-ISC Features

  • Integrated Control Panel
  • OSD With Multi-Language Support
  • Wall Mount VESA Compliant ( 75 X 75 mm)
  • Integrated Stereo Speakers
  • 3 Year Standard Warranty
  • Option For Integrated MSR, Speakers
  • Option For Custom Logo and Case Colour

Request a Quote

Product Type

IP Rating

Screen Size

Manufacturer

Country Of Manufacture

Taiwan

Certifications

CE, UL

Custom Options Products

Cable Type,Cable Length,Custom Logo,Case Colour

Dimensions

TBD

Display Accessories Included

AC/DC Power Adapter

Active Display Area

115.2 (H) x 86.4 (V)

Aspect Ratio

0.16875

Backlight Life

35,000 hours (typ)

Connectivity

PC Signal 15 Pin female D-Sub x 1, PC Audio Stereo headphone jack x 1, Power Plug 12 VDC jack

Contrast Ratio

33.33402778

Display Backlight

LED backlight

Display Brightness

400 cd/m2

Display Resolution

640 x 480

Frequency Range

Fh: 30 to 82Khz, Fv: 60 to 75Hz

Housing Material

Metel

Input Power

Universal/ Auto-sensing, 90 to 260VAC, 50/60 Hz

Mounting Type

Desktop

Osd Control

No

Pixel Dimension

0.18 (H) x 0.18 (V) mm

Power Consumption

Operation 5 Watt ( Max ) Stand-by < 1 Watt

Power Management

DPMS Compatible

Response Time

< 25 ms

Screen Technology

LCD

Screensize

5.7"

Sync Signal

Separate Sync, Composite Sync, Sync on Green

Video Signal

Analog RGB (0.7/1.0 Vp-p, 75 ohms)

Viewing Angle

160 degree in horizontal & 140 in vertical (typ)

Operating Temperature

OPERATING: 0C to +40C

Storage Temperature

STOREAGE: -20C to +60C

Temperature Rating

OPERATING: 0C to +40C / STOREAGE: -20C to +60C

The RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the RD-0571-ISC is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence

These examples highlight the versatility of the RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display, Rugged Display fits your specific needs, please contact us.

The RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display comes with a 1 Years RTB Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RD-0571-ISC 5.7″ Industrial Rugged Display?

If you have any questions about the RUGGED RD-0571-ISC please get in touch today, our team of technical experts are ready to assist you.
