RUGGED RKB-M380TP-FN Industrial Rugged Keyboard

85 keys IP65 dynamic vandal proof industrial keyboard with adjustable industrial backlight, sealed & ruggedized tough touchpad for fast and accurate cursor position, with FN (F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12) on the top line for easy operation, with industrial PCB with carbon-on-gold key switch technology with key stroke 1.50mm with extremely good tactile feeling for fast and accurate input without any noise, red clean key lock/disable the keyboard for easy cleaning and washing without needing to take out the keyboard from PC, high quality durable black titanium electroplated on the top stainless steel plate (optional), adjustable industrial blacklight included, rear panel mounted. Dimensions: 380.0mm x 129.5mm (top panel)

RKB-M380TP-FN Features

  • Rugged Panel Mount Keyboard
  • Integrated Touchpad
  • IP65 Rated

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

China

Case Material

Silicone Rubber

Certifications

RoHS , CE, FCC, ESD

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

380.0mm x 129.5mm

Humidity

90% Humidity Resistant

Compatibility

All Windows, Linux, Unix, Mac OSX, Vxworks, Android

Dimension with Trackball

380.0mm x 129.5mm

EMC

IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004

EMI

EN 55022: 2010

EMS

EN 55024:2010

Frontplate Material

1.5mm Stainless Steel Plate With Super Quality Durable Black Titanium Electroplated (Optional)

Key Spacing

11.4mm x 11.4mm for normal keys, 11.4mm x 24.3mm for enter key, 11.4mm x 71.8mm for space bar.

Key Switch

Carbon-on-Gold key Switch Technology

Lifespan

> 3 years

Material (Bottom Plate)

1.5mm Stainless Steel Plate.

MTBF

>50000H

MTTR

<30min

No. Of Keys

85

Pointing Device

Touchpad

Supply Current

17 mA

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

1.50mm

Length

380.0mm

Operating Temperature

Operating temperature:-20C to +60C

Storage Temperature

Storage temperature: -30C to +70C

Temperature Rating

Operating temperature:-20C to +60C - Storage temperature: -30C to +70C

Width

129.5mm

The RUGGED RKB-M380TP-FN Industrial Rugged Keyboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the RKB-M380TP-FN is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence

These examples highlight the versatility of the RUGGED RKB-M380TP-FN Industrial Rugged Keyboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The RUGGED RKB-M380TP-FN Industrial Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RKB-M380TP-FN Industrial Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RKB-M380TP-FN Industrial Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RKB-M380TP-FN Industrial Rugged Keyboard or require a custom solution?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RKB-M380TP-FN or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
