RUGGED RKP-D80-19 Industrial Rugged Keypad

19 keys compact format IP65 dynamic water proof industrial membrane keypad with industrial electronics controller included, industrial OMRON switch technology with short stroke 0.45mm with extremely good tactile feeling for reliable data input, surface mounted extremely flush with anti-microbial functionalities, the fonts printed on the film underneath will never fade, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments, ruggedized and backed with 3.0mm Aluminium plate with sand blasting & oxygenation treatment, with top panel mounted solution, industrial level. Dimensions: 80.0mm x 143.0mm (L x W)

RKP-D80-19 Features

  • Rugged Panel Mount Keypad
  • IP65 Rated
  • Stainless Steel Construction

Request a Quote

Product Type

IP Rating

Manufacturer

Country Of Manufacture

China

Case Material

Stainless Steel

Certifications

RoHS , CE, FCC, ESD

Custom Options Products

Cable Type,Cable Length,Interface,Keypad Layout

Dimensions

80.0mm x 143.0mm

Housing Colour

Stainless Steel

Humidity

90% Humidity Resistant

Base plate Material

Epoxy resin gilding

Compatibility

All Windows, Linux, Unix, Mac OSX, Vxworks, Android

EMC

EMC directive 89/336/EEC EN55022: 1988+A1:2000+A2:2003 EN55024: 1988+A1: 2001+A2:2003

EMI

EN 50081-1

EMS

EN 50081-1

Frontplate Material

1.5mm Thickness Super Quality Brushed Stainless Steel

Key Material

Stainless Steel

Key Spacing

12.0mm X 13.0mm for normal keys, 22.5mm x 13.0mm for enter key

Key Switch

Carbon-on-Gold key Switch Technology

Lifespan

> 3 years

Material (Bottom Plate)

Back Stainless Steel Housing: 1.0mm Thickness Super Quality Stainless Steel

MTBF

>50000H

MTTR

<30min

No. Of Keys

19

Operating Force

2.0N+/-0.1N for key 14.0mm x 14.0mm (pressure point)

Supply Current

20mA (non-backlight), 140mA (with backlight on)

Supply Voltage

+5V DC +/-5%

Switch / Key Travel

1.5mm

Length

80.0mm

Operating Temperature

Operating temperature:-20C to +60C

Storage Temperature

Storage temperature: -30C to +70C

Temperature Rating

Operating temperature:-20C to +60C (industrial level)-40C to +85C Storage temperature: :-30C to +70C (industrial level)-55C to +150C

Width

143.0mm

The RUGGED RKP-D80-19 Industrial Rugged Keypad is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the RKP-D80-19 is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence

These examples highlight the versatility of the RUGGED RKP-D80-19 Industrial Rugged Keypad across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keypad, Rugged Keypad fits your specific needs, please contact us.

The RUGGED RKP-D80-19 Industrial Rugged Keypad comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, RUGGED RKP-D80-19 Industrial Rugged Keypad, must be presented to RUGGED in the United Kingdom.

For more information about the RUGGED RKP-D80-19 Industrial Rugged Keypad or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the RUGGED RKP-D80-19 Industrial Rugged Keypad or require a custom solution?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the RUGGED RKP-D80-19 or need a custom Keypad solution designed specifically for you, our team of technical experts are ready to assist you.
