iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad

The SBW-97-TP is the first rechargeable, wireless rugged keyboard with the unique ability to pair to a USB dongle over a 802.11G wireless frequency. Unlike traditional wireless keyboards, pairing of the SBW-97-TP does not require the user to press a button on the USB radio dongle or interact with the computer operating system. Once the USB dongle has been installed in the host computer, pairing is only a two keystroke procedure. This exclusive feature allows for a keyboard to be moved from computer to computer and paired for operation directly at the keyboard.   The SBW-97-TP is rechargeable via the provided micro USB connection and stays charged for approximately 2 weeks with regular use. Manufactured with an integrated touchpad pointing device, the SBW-97-TP offers LED indicators for pairing, battery life, and charging, and it can be mounted for added ease of use.  Optional magnetic mounting is available. With a fully-sealed industrial silicone rubber pad and polycarbonate case, the SBW-97-TP is engineered for NEMA 4x specifications, making it resistant to water, dust, and compatible with hospital cleaning agents. Featuring a  CleanLock™ key, the SBW-97-TP can be quickly disabled during the sanitizing process making this  keyboard ideal for use in ORs, patient rooms, medical carts, and nursing stations.

SBW-97-TP Features

  • USB Rechargeable
  • Wireless 802.11 RF
  • 84-Key Functionality + 12 Function Keys
  • Compatible With Hospital Cleaning Agents + Clean Lock
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

No Backlight

Case Material

ABS Polycarbonate

Certifications

IP Rated, NEMA 4X, CE UL60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

14.96" x 5.91" x 0.84" (w-h-d) 379.984mm x 151.9 mm x 21.3mm

Housing Colour

White / Medical White

Humidity

100% Humidity Resistant

Cable

Pairable Dongle - USB interface

Compatibility

KEYBOARD: Wireless interface connects to included USB Dongle All Windows Operating Systems

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial silicone rubber LIFE: Greater than 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with mechanical snap

Lifespan

>10 Million Actuations

No. Of Keys

84

Pointing Device

Touchpad

Power

Wireless 802.11 RF, USB Rechargeable Polymer Lithium-Ion Battery. 860mAh

Product Weight

1.4 lbs +/- 0.10 lbs (0.64 kg +/- 0.05 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Length

88.0mm

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to + 60C ( -4F to +140F)

Width

88.0mm

The iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the SBW-97-TP is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Medical and Healthcare, Military and Defence, Pharmaceutical

These examples highlight the versatility of the iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad, must be presented to RUGGED in the United Kingdom.

For more information about the iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey SBW-97-TP Wireless Medical Rugged Keyboard With Touchpad or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iKey SBW-97-TP or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
