Adder Technology TS4 KVM Switch
Compatibility
The ADDER TS4 is compatible with all common computers and operating systems including PC, Sun, Bloomberg and Apple. Choice of switching method
As with all ADDER switching products, the ADDER TS4 can switch from one computer to another by using keyboard hotkey combinations, three button or wheel mouse or the button on the TS4 itself. The selected channel is shown on the 7-segment display. Remote switching options
There are two remote switching options, ADDER’s RC1, which provides a low profile, single button switch with a 7-segment LED display or the specifically designed TS4 remote unit, which has a button and LED display per connected computer. Compact design
To help keep desks tidy and ease the management of cables, the ADDER TS4 has been designed to fit into the cable baskets commonly found on the back of traders’ desks.
TS4 Features
- Four Way Keyboard and Mouse Switch
- Sun, PC and Mac Compatible
- PS2 Connection
- Increased Switching Capabilities
- Choice Of Switching Methods Including Remote
- VGA, RS232 Interface
- Features PS2 Connection
Request a Quote
Product Type
Format
Manufacturer
Country Of Manufacture
United Kingdom
Case Material
Robust Metal Case
Certifications
CE, RoHS compliant
Additional Accessories
RC1: Remote control keypad
RC4: 4 button remote control switch with 2m cable
CCSUN: Converter for connecting a SUN computer to the Adder unit
VSC3: PS/2 style keyboard/mouse cable 2m
CCP2U: USB to PS/2 converter cable, USB type A to 2x
Cables
SmartView to keyboard, mouse and monitors - 2m if interface powered or 10m if PSU used. SmartView to computers - 5m if interface powered or 30m if PSU used. Adder 3-in-1 KVM cables recommended for keyboard, mouse and first video ports. High quality tri-c
Case Material
Robust Metal Case
Computer Connections
Keyboard/Mouse: MiniDin6 Remote control: serial DB15
Computer Connections RX
All RJ45 style Network port (ADDERView IP models only) RJ45 10/100Mb auto-sensing Ethernet port
Computer Connections At Switch
Video: HDD15,
Keyboard/Mouse: MiniDin6
Serial: DB9 female
Computer Selection
Computers may be selected using the front panel key, keyboard hotkeys, a three button mouse or wheel mouse, RS232 data commands or the optional remote controller. The hotkeys are selectable and are designed to be quick-fire using a minimum number of key p
Controls
Front panel key for computer selection. Numerical display shows selected computer and keyboard/mouse activity. Optional remote controller connects to rear. Base-mounted reset and option switches.
Flash Upgrades
Flash upgradeable to support new devices by connecting a computer's serial port to the options port and running a download program.
Hardware Compatibility
Supports PC, RS/6000, Alpha and SGI computers using PS/2 or Sun (USB & 8-pin styles) and Mac (USB) when using the appropriate CCUSB/CCSUN interface cables.
Keyboard Ports
PS/2 or AT style keyboards supported. PS/2 keyboards plug in directly. AT keyboards require a 6-pin mini-DIN to 5-pin DIN adapter. Automatic mode emulation and num / caps / scroll updates ensures that the keyboard is always in the expected state. Modes 1,
Keyboard Support
PS/2 or AT style keyboards supported. PS/2 keyboards plug in directly. AT keyboards require a 6-pin mini-DIN to 5-pin DIN adapter. Automatic mode emulation and num / caps / scroll updates ensures that the keyboard is always in the expected state. Modes 1,
KVM Connections
All connectors are rear mounted to ensure a neat installation and are colour coded according to the PC99 specification (keyboard=violet, mouse=green, video=blue) for easy identification. Keyboard and mouse ports use 6-pin mini-DIN female connectors. Video
KVM Connectors
All connectors are rear mounted to ensure a neat installation and are colour coded according to the PC99 specification (keyboard=violet, mouse=green, video=blue) for easy identification. Keyboard and mouse ports use 6-pin mini-DIN female connectors. Video
Local Console
Video: HDD15
Keyboard/Mouse: MiniDin6
Serial: DB9 male
Options/Flash upgrade port: DB15 female
Local KVM Console Connection
Local console connections as stated above. CATx computer connections: all RJ45 style. 10/100 auto-sensing Ethernet network port: RJ45. Power connection: 2.5mm DC jack (5V DC, 2.5A). RS232 triggered power switching and syncing: DB9 plug
Mouse Ports
The controlling PS/2 style mouse plugs directly into the SmartView. SmartView supports 2 and 3 button mice and most wheel and scroll mice including the Microsoft IntelliMouse and IntelliMouse Explorer. PS/2 or RS232 mouse connections to computers may be m
Mouse Support
The controlling PS/2 style mouse plugs directly into the SmartView. SmartView supports 2 and 3 button mice and most wheel and scroll mice including the Microsoft IntelliMouse and IntelliMouse Explorer. PS/2 or RS232 mouse connections to computers may be m
No. Of Ports
4
Operation Mode
The keyboard, mouse and all the video heads are switched together so that the keyboard and mouse are controlling the computer whose video is currently displayed on the monitors.
Options Port Control
Plugs into the options port at the rear of the SmartView. Duplicates the SmartView's front panel key and numerical display. May be attached to the top of a keyboard or the side of a monitor by the Velcro strips supplied. 60 x 29 x 12 mm. White / cream fin
OS Compatibility
All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc.
Physical Design
All Metal Case
Power
Interface powered via PC keyboard connection
Rackmount Options
RMK1 19" 1U rack mount kit included
Software Compatibility
All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc
Sync Switching
SmartView MultiScreens may be linked together via their options ports to provide synchronized switching of 8, 12 or 16 video channels controlled from one master unit.
System Connections
All connectors are rear mounted to ensure a neat installation and are colour coded according to the PC99 specification (keyboard=violet, mouse=green, video=blue) for easy identification. Keyboard and mouse ports use 6-pin mini-DIN female connectors. Video
User Console Connections
2 x 6 way mini DIN female connectors for controlling keyboards.
2 x 6 way mini DIN female connectors for controlling mice.
2 x 15 way HD D Female for controlling monitors.
1 x RJ45 port for remote user.
2 x 5V DC 2A power inlets for ex
Video Modes
High bandwidth video supported at resolutions up to 1920 x 1440. Low distortion and excellent video transfer characteristic. Supports VGA / SVGA / XGA / XGA-2 / SXGA and UXGA video and VESA DDC1 and DDC2 signalling. Screen saver feature with user selectab
Video Ports
High bandwidth video supported at resolutions up to 1920 x 1440. Low distortion and excellent video transfer characteristic. Supports VGA / SVGA / XGA / XGA-2 / SXGA and UXGA video and VESA DDC1 and DDC2 signaling. Screen saver feature with user selectabl
Operating Temperature
OPERATING: 0C to +40C
Ordering Info
SVMS4-S: 4 port single video head, single serial head KVM switch SVMS4-DS: 4 port dual video head, dual serial head KVM switch
The Adder Technology TS4 KVM Switch is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the TS4 is commonly used:
These examples highlight the versatility of the Adder Technology TS4 KVM Switch across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this KVM, KVM Switch fits your specific needs, please contact us.
The Adder Technology TS4 KVM Switch comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Adder Technology TS4 KVM Switch, must be presented to RUGGED in the United Kingdom.
For more information about the Adder Technology TS4 KVM Switch or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Adder Technology TS4 KVM Switch?
If you have any questions about the Adder Technology TS4 please get in touch today, our team of technical experts are ready to assist you.
