Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC
The Winmate R15FA3S-EHC3 is a 15-inch HMI (Human-Machine Interface) panel PC powered by the NXP i.MX6 processor. Designed for industrial control systems, this panel PC provides reliable performance in automation, manufacturing, and factory settings. The fanless design ensures quiet and maintenance-free operation, while the robust construction is built to withstand harsh environments. The responsive touchscreen interface allows for easy interaction with control systems, and the wide range of I/O options provides flexibility for system integration. Ideal for applications where durability and user-friendly operation are critical, the R15FA3S-EHC3 is a dependable choice for industrial HMI tasks.
R15FA3S-EHC3 Features
- 15” 1024 x 768 Resolution with Projected Capacitive Multi-Touch (PCAP)
- NXP i.MX6 Dual Core 1 GHz
- Fanless cooling system and Ultra-low power consumption
- Support PoE function
- Front IP65 Water and Dust Proof
- 1 x USB ; 1 x RS232 / 422 / 485 ; 1 x Micro SD Slot
Request a Quote
Size
15.0 inches
Touch / Glass
Projected Capacitive Multi Touch Screen
Resolution
1024x768
Panel Brightness
300.0 nits
Contrast Ratio
2000:1
View Angles
88-88-88-88
Active Area
304.1x228.1 mm
Processor
NXP i.MX6 Dual Core- 1.0GHz
Memory
1GB 2GB (Optional)
Storage
eMMC: Onboard 16 GB eMMC: Onboard 32 GB (Optional)
Operating System
Linux Ubuntu 18.04 (Optional) Android 6.0 (Optional) Debian 7.0 (Optional) Linux 4.1.15 QT 5.5 (Optional)
Dimension
353 x 277 x 42 mm
Cut out
336x266mm
Weight
3.0 kg
Mounting
Panel mount VESA Mount
Enclosure
Metal Front Bezel with Plastic Back Cover
Cooling System
Fanless design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
USB Port
1 x Console Port (Mini USB) 1 x USB OTG 1 x USB2.0 (Type-A)
Serial Port
1 x RS232/422/485 (Default RS232)
LAN
1 x LAN RJ45 Connector with PoE(PD- 802.3 at)
Video
1 x Micro HDMI (Optional)
SD Card Slot
1 x Micro SD card slot
Expansion Port
1 x mPCIe slot(for Wi-Fi module)
CANBUS
1 x CANBUS- D-sub9
Power Input
1 x 12V DC- 2-Pin Terminal Block
Accessory
100~240V AC to DC Adapter Power Cord VESA screws Mounting clips
Power Rating
12V DC
Adapter
12V 50W
The Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the R15FA3S-EHC3 is commonly used:
These examples highlight the versatility of the Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Panel PC, Rugged Panel PC fits your specific needs, please contact us.
The Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate R15FA3S-EHC3 15 Inch NXP i.MX6 E Series HMI Panel PC or require a custom solution or demonstration?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Winmate R15FA3S-EHC3 or need a custom Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
