Cursor Controls X13 OEM Trackball
Utilizing the latest and most advanced laser tracking technology, the X13 series laser Trackerball™ is an extremely high specification, contact-less device, ideal for the most demanding of cursor control applications. The laser tracking engine provides accurate cursor motion at all speeds, combining the benefits of solid state sensing (no moving parts except the ball) with the aesthetics, functionality and performance associated with the Cursor Controls product range. The design incorporates a removable top ring as standard to allow for easy cleaning, decontamination, sterilisation and maintenance – ensuring continued optimum performance and operation under the harshest of conditions. The X13 trackballs are available with a variety of electrical outputs, tracking force options, and sealing capabilities up to IP68. The trackball has been designed to be back of panel mounted as part of OEM keyboards and consoles.
X13 Features
- Solid State Sensing Technology
- Sealing Up To IP68
- USB & PS2 (Auto-Select) Or Sun Systems
- Smooth Operation In Rugged Environments
- Various Top Plate Configurations
- Custom Connector Options
- Custom Mounting Bracket Options Available
Request a Quote
Product Type
Format
Manufacturer
Country Of Manufacture
United Kingdom
Case Material
ABS Polycarbonate
Certifications
CE, RoHS compliant
Custom Options Products
Cable Type,Cable Length,Interface,Trackball Colour
Housing Colour
Black
Humidity
30% min, 95% max, non-condensing
Lifetime
>10 million ball revolutions
Storage Temperature
Storage Temperature -25C to + 85 C
Temperature Rating
Operating Temperature 0C to +70C
Storage Temperature -25C to +85 C
Ball
Thermoset Phenolic or Polyester, 63mm
Ball Load
200N Maximum downward pressure (20Kg) @ 20C
Ball Rotation
Continuous and reversible in any direction
Ball Speed
200 RPM maximum
Housing Material
ABS
Mounting Filter
Rear Mount
Mounting Position
Horizontal to 30
Power
Supply Voltage 5 V DC +/- 5%
Supply Current Protocol format 10ma typical
Optional Backlight +5 V DC, 100ma
Resolution
440 pulses per ball revolution (other options available upon request)
Tracking Force
15gms Nominal continuous no seal (IP40)
Transducers
Photo-optical encoders with LEDS
The Cursor Controls X13 OEM Trackball is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the X13 is commonly used:
Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence
These examples highlight the versatility of the Cursor Controls X13 OEM Trackball across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Rugged Trackball, Trackball fits your specific needs, please contact us.
The Cursor Controls X13 OEM Trackball comes with a 18 Month Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Cursor Controls X13 OEM Trackball, must be presented to RUGGED in the United Kingdom.
For more information about the Cursor Controls X13 OEM Trackball or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Cursor Controls X13 OEM Trackball or require a custom solution or demonstration?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Cursor Controls X13 or need a custom Trackball solution designed specifically for you, our team of technical experts are ready to assist you.
