iKey BT-870-TP Bluetooth Rugged Keyboard

The BT-870-TP dual connectivity rugged keyboard.  Connect with USB or Bluetooth®. This keyboard has a built-in touchpad and is made of industrial silicone rubber.

This fully-sealed rugged keyboard is designed to meet IP67 and NEMA 4X specifications, meaning it is resistant to dirt, dust, water, ice and corrosives. Built with an industrial silicone rubber keypad and a rugged ABS polycarbonate case, the BT-870-TP is easy to clean with disinfectants. The compact design and internal Bluetooth® module make the BT-870-TP highly portable. In addition, its red LED backlighting is ideal for nighttime or ambient-light use.

A MicroUSB cable is included to recharge the keyboard and turn it into a wired USB keyboard when necessary. Includes 75mm VESA and 1.188” x 1.5” AMPS mounting patterns

BT-870-TP is an ideal fit for mobile, material handling, food and beverage processing, medical, and other environments where rugged flexibility is a necessity. It is rated IP67.

The BT-870-TP is available for immediate order.

BT-870-TP Features

  • Dual Connectivity
  • Connect with USB or Bluetooth
  • Red LED Backlighting
  • IP67
  • Built-in Touchpad

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

Red

Case Material

ABS Polycarbonate

Certifications

CE, RoHS compliant

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

12.01" x 7.75" x 2.03" (lwh)

Housing Colour

Black

Humidity

100% Humidity Resistant

Compatibility

USB: All Windows and Macintosh OS

Connectivity

Wireless , Bluetooth

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles Travel: 0.055in.

Lifespan

>10 Million Actuations

No. Of Keys

87

Pointing Device

Touchpad

Product Weight

2.0 lbs +/- 0.010 lbs

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY .04G/HZ FREQUENCY RANGE: 20Hz-2Khz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40⁰F TO +149⁰F (-40⁰C to +65⁰C). OPERATING: 32⁰F to +140⁰F (0⁰C to +60⁰C)

The iKey BT-870-TP Bluetooth Rugged Keyboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the BT-870-TP is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Medical and Healthcare, Military and Defence, Outdoor and Mobile Computing, Pharmaceutical, Public Safety and Emergency Services, Transport and Logistics

These examples highlight the versatility of the iKey BT-870-TP Bluetooth Rugged Keyboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The iKey BT-870-TP Bluetooth Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey BT-870-TP Bluetooth Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey BT-870-TP Bluetooth Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey BT-870-TP Bluetooth Rugged Keyboard or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iKey BT-870-TP or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
