iKey DT-810 Desktop Rugged Keyboard

The DT-810 is a small-footprint industrial keyboard featuring an integrated Hula Point IITM pointing device. It is fully sealed in a stainless steel case and is NEMA 4X-certified, which means it is resilient to grease, dirt, water and corrosive liquids commonly found in industrial environments.

The DT-810 has 81 keys, including 12 function keys. iKey also offers the DBL-810, which has the same layout as the DT-810 but features LED backlighting for low-light environments.

DT-810 Features

  • 81-Key Functionality
  • Integrated Pointing Device
  • 12 Function Keys + Fn Key For Secondary Legend Flexibility
  • USB and PS2 Configurations Available
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

IP Rating

Manufacturer

Country Of Manufacture

United States

Backlight

No Backlight

Case Material

Stainless Steel

Certifications

IP Rated, NEMA 4X, CE UL-60950, FCC Part 15 Class B

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

16.12" x 7.02" x 1.74" (w-h-d) 409.4mm x 178.3mm x 44.2mm

Housing Colour

Stainless Steel

Humidity

100% Humidity Resistant

Cable

LENGTH: 10 feet straight (3 m) DESIGN: "Y" PS/2 Cable (providing separate keyboard and mouse connections), or single-cable USB

Compatibility

PS/2 KEYBOARD/HULAPOINT: All Windows Operating Systems USB KEYBOARD/HULAPOINT: All Windows and Macintosh OS

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Tactile with Mechanical Snap

Key Material

Industrial Silicone Rubber

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater Than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz +/- 1.06 oz (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Lifespan

>10 Million Actuations

No. Of Keys

81

Pointing Device

HulaPoint

Power

PS2: KEYBOARD: 50mA@5V (from Keyboard port) POINTER: 35mA@5V (from Mouse port) USB: 85mA@5V (from CPU port)

Product Weight

3.75 lbs +/- 0.10 lbs (1.70 kg +/- 0.05 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Switch Force

200g (+/- 30g)

Switch / Key Travel

0.055 in (1.4mm)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)

The iKey DT-810 Desktop Rugged Keyboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the DT-810 is commonly used:

Aerospace, Industrial and Manufacturing, Marine and Offshore, Military and Defence

These examples highlight the versatility of the iKey DT-810 Desktop Rugged Keyboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The iKey DT-810 Desktop Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey DT-810 Desktop Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey DT-810 Desktop Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey DT-810 Desktop Rugged Keyboard or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iKey DT-810 or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
