iBASE BST-1850 Panel PC
The BST-1850 multi-touch bedside terminal is a multifunctional slim 18.5 panel PC designed especially for bedside medical care applications. It wins 2013 Taiwan Excellence Award, the symbol of Taiwan Excellence is a distinctive, proprietary logo and the unique trademark for Taiwan’s innovalue.
BST-1850 Features
- Medical 18.5" Panel PC
- Ideal For Bedside, Medical Care Applications
- IP65 (Monitor Front Panel)
- I/O Cover For Cables Arrangement
- Integrated Aluminum Housing, Perfect Thermal Design
- 12V To 24V DC ( 20%) Wide-Range Power Input
Request a Quote
Product Type
Format
IP Rating
Operating System
Processor
Manufacturer
Country Of Manufacture
Taiwan
Case Material
Aluminum
Certifications
CE, RoHS compliant
Custom Options Products
Interface,Processor,Memory,Storage,Connections,Operating System
Dimensions
Indicator: 458 x 355 x 36 Main body: 130 x 300 x 60
Humidity
-10C~50C
Operating System
Windows
Operating Temperature
0C~ 40C
Ordering Info
BST-1850 18.5ï¾€ï¾ Panel PC with capacitive multi-touch AMD 1.6GHz CPU, 16GB 2.5" SSD, 2GB DDR3-1066
Additional Graphics
None
Audio
Audio (In x 1, Out x 2)
Backlight Lifetime(hrs)
30000
Built-in Speaker/MIC
2x Speaker
Chassis Material
Aluminum sliver with front bezel hairline
Construction
Plastic/Monitor Steel/Computing
Contrast
41.667361111111
Digital I/O
None
Display Interface
1x LVDS 1x DVI-I
Display Type
18.5" TFT LCD
Expansion Slot
None
HDD
2x SATA2.0
Internal Expansion Bus
1x Mini PCI-E half/full size 1x Mini PCI-E half size
Interface
USB
Keyboard/Mouse
None
LAN
IEEE802.11n/b/g standard wireless LAN, 2x LAN
Light Transmission (%)
83
Luminance (cd/m2)
250
Max. Color
16.7M
Max. Resolution
1366 x 768
Membrane Control
None
Memory
2GB DDR3-1066
Mounting
VESA 100 x 100mm (Monitor) Wall mounting (Computing)
Mounting Type Filter
VESA
Onboard Expansion Bus
1x Mini PCI-E half/full size
Operating System Support
Windows Embedded Standard XP, Windows Embedded Standard 7, Windows 7 Pro for Embedded
Point of touch
2
Power
12VDC ï¾± 5% (AC adaptor is included)1 Push button
Power Button
Rock switch
Power Input
12VDC ï¾± 5% (AC adaptor is included)
Power Input Range
12V~24V DC
Processor, Chipset
AMD Fusion T56N 1.6GHz AMD A55E *Power-saving CPU type also supported
Removable Slot
16GB 2.5" SSD
RS-232
1
RS-232/422/485 Selectable under BIOS
1
Serial/Parallel
None
Thermal Design
Fanless
Touch Type
Projected capacitive touch
Touch Type Filter
Projected Capacitive Touch
USB
4x USB 2.0 (indicator2 / Main body 2)
USB 2.0
0
USB 3.0
3
View Angle (H/V)
170/160
Wireless
Optional Wi-Fi/BT
Processor
Intel
Storage Temperature
-10C~50C
The iBASE BST-1850 Panel PC is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the BST-1850 is commonly used:
These examples highlight the versatility of the iBASE BST-1850 Panel PC across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Panel PC, Rugged Panel PC fits your specific needs, please contact us.
The iBASE BST-1850 Panel PC comes with a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE BST-1850 Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE BST-1850 Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE BST-1850 Panel PC or require a custom solution?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iBASE BST-1850 or need a custom Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
