iBASE FWA6604 Network Appliance
The FWA6604 compact network appliance is a device with four Gigabit Ethernet ports based on Intel I211-AT Gigabit Ethernet controllers. The model comes in two flavours – a Fanless version powered by an Intel Atom E3815, 1.46GHz processor and another one built around an Intel Celeron J1900, 2.0GHz processor.
FWA6604 Features
- Onboard Intel" Celeron" J1900 Soc, 2.0GHz
- Advanced LAN Bypass
- 4X Intel" I211-At GBE Ports
- 1X Cf Socket, 1X SATA Connector, 2X USB 2.0
- 1X Factory Default Button (Programmable)
Request a Quote
Product Type
Format
Processor
Manufacturer
Country Of Manufacture
Taiwan
Certifications
CE, RoHS compliant
Dimensions
187mm (W) x 115.8mm (D) x 44mm (H) 7.36" (W) x 4.56" (D) x 1.73" (H)
GbE Ports
4
Humidity
5%-90% Humidity Resistant
CPU
Intel Celeron Quad Core Processor J1900 (2M Cache , 2.0 GHz)
Expansion Slots
1x half-size Mini PCI-E (USB signal only)
LAN
4x Intel I211-AT GbE LAN 3/4 Bypass
LED
Power / Bypass / Status LAN activitity (Bypass & status LED is programable by software.)
Memory
1x DDR3L-1333 SO-DIMM, up to 8GB (non-ECC)
No. Of Ports
4 GbE Ports
Ports filter
4
Power Supply
Full range 40W power adapter / 12V
Serial I/O
1x RJ-45 console
Storage
1x CF socket, 1x SATA connector
TPM
TPM 1.2
USB
2x USB 2.0 ports on board 1x USB 2.0 port pin header
VGA
Via pin header (internally)
Operating Temperature
0C~ 45C (32CF~113CF)
Ordering Info
IB831-NB VIA Nano X2 Dual Core 5.25ï¾€ï¾ Disk-Size SBC w/ 4x GbE LAN, 1x SATA II, w/o Bypass IB831 VIA Nano X2 Dual Core 5.25ï¾€ï¾ Disk-Size SBC w/ 4x GbE LAN, 1x SATA II, with Bypass PS2G PS/2 keyboard and mouse cable VGA8 VGA cable
Processor
Intel
Storage Temperature
-20C ~ 70C (-4CF~158CF)
The iBASE FWA6604 Network Appliance is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the FWA6604 is commonly used:
These examples highlight the versatility of the iBASE FWA6604 Network Appliance across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Network Appliance fits your specific needs, please contact us.
The iBASE FWA6604 Network Appliance comes with a Standard Manufacturers Limited Warranty + Option to Extend against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, iBASE FWA6604 Network Appliance, must be presented to RUGGED in the United Kingdom.
For more information about the iBASE FWA6604 Network Appliance or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the iBASE FWA6604 Network Appliance?
If you have any questions about the iBASE FWA6604 please get in touch today, our team of technical experts are ready to assist you.
