Robustel R1520G-OG IP67 Rated Outdoor Router

The R1520G-OG is an IP67 rated outdoor router (including TPH-R1520 and R1520-4L Global) that is ideal for adding Wi-Fi internet access at events, on campuses or when rugged housing is required for indoor deployments.

Around 50% of the space inside the enclosure is available for customers to add their own electronics providing a semi-bespoke solution for outdoor deployments of industrial equipment. OEM branding of the enclosure is possible for high volume projects.

Some of the advanced features include:

  • Smart Roaming – A unique network selection algorithm that intelligently selects networks when using 3G/4G roaming SIM cards “ providing maximum reliability.
  • RobustVPN – A highly flexible hosted VPN service that allows customers to make an inbound connection to the router and attached equipment from anywhere in the world.
  • Power over Ethernet – Ethernet Port 0 supports PoE-PD to make installation easy “ just a single M12-terminated cable is required to get power + data to and from the box.
  • RCMS (Robustel Cloud Manager Service) – Very high-quality Microsoft Azure based router management platform available for simple estate management. Basic version completely free “ advanced functions are pay as you go.

R1520G-OG Features

  • IP67 ingress protection withstanding water, dust, and other extreme weather conditions
  • Space inside enclosure for user-specific electronics to be added
  • Globally certified*
  • Supports dual-SIM cellular, Wi-Fi and Ethernet
  • Fully programmable router
  • RCMS – free, high quality cloud platform for remote management
  • Supports SMS commands for remote configuration/recovery in fault conditions
  • Captive Portal function optional
  • VPN Support includes OpenVPN, IPSEC, Wireguard + more

Request a Quote

Manufacturer

Country Of Manufacture

China

Antenna Connectors

M16, N female

Available Apps

L2TP, PPTP, DMVPN, VRRP, QoS, Captive Portal, WLAN Multi AP, SNMP, Language, RCMS

Case Material

Rugged Plastic

Cellular Connectors

2

Cellular Region

Global ,UK,EMEA,USA,Australia,China,Europe,India,Japan,New Zealand,North America,Oceania,South America

Custom Options Products

Custom Logo,Case Colour,Connections,Conformal Coating,Anti-Bacterial Coating,Laser Etching,Power Supply,Mounting Options

Dimensions

310 x 245 x 93.4 mm

Enclosure

Plastic, 2008g including R1520, excludes antennas and mounting hardware

Ethernet

M12 A-coded, 8PIN, Number of internal ports 4 x 10/100 Mbps Ethernet

Ethernet Ports

1 x 10/100 Mbps Ethernet supporting 802.3af/at PoE-PD (ETH0 only)

Housing Colour

White

Humidity

5 ~ 95% RH

Magnet Isolation Protection

1.5 KV

Operating Temperature

Minus 25 degrees celsius to 70 degrees celsius

Power Input

9 ~ 36 V DC

Power Supply Connector

M12 A-coded PoE-PD or optional DC via 3-pin connector

SIM Slots

2, Mini-SIM or eSIM (Optional)

Storage Temperature

-40 ~ +85 °C

WI-FI Antennas

2

WI-FI Connectors

M16, N female

WI-FI Data Speed

2 x 2 MIMO, 300 Mbps

WI-FI Encryption

64/128 AES, TKIP

WI-FI Frequency Bands

2.4 GHz

WI-FI Security

WEP, WPA, WPA2

WI-FI Standards

802.11 b/g/n, supports AP and Client modes

The Robustel R1520G-OG IP67 Rated Outdoor Router is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the R1520G-OG is commonly used:

Industrial and Manufacturing, Medical and Healthcare, Outdoor and Mobile Computing, Pharmaceutical, Public Safety and Emergency Services, Transport and Logistics

These examples highlight the versatility of the Robustel R1520G-OG IP67 Rated Outdoor Router across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Cellular Router, Rugged Router fits your specific needs, please contact us.

The Robustel R1520G-OG IP67 Rated Outdoor Router comes with a 2 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, Robustel R1520G-OG IP67 Rated Outdoor Router, must be presented to RUGGED in the United Kingdom.

For more information about the Robustel R1520G-OG IP67 Rated Outdoor Router or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the Robustel R1520G-OG IP67 Rated Outdoor Router or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Robustel R1520G-OG or need a custom Cellular Router solution designed specifically for you, our team of technical experts are ready to assist you.

  • Alternative Products

    Discover a range of alternatives that offer comparable features and quality to the product you’re viewing.

    Our selection of similar items provides diverse options, allowing you to explore different designs, functionalities, and styles tailored to your preferences. Each product has been carefully chosen to ensure it meets the high standards you expect, enabling you to make a well-informed decision based on your unique requirements.

    Browse through our related products and find the perfect match that complements your choice seamlessly.

    • Global 4G frequency coverage for all continents
    • Huge investment in Global certifications for all major countries
    • Free Cloud Management platform for easy global monitoring
    • Supports WWAN, WAN, WLAN link backup and ICMP detection
    • Supports cold backup , warm backup and load balancing
    • RobustOS + SDK + App
    • Highly stable 2G/3G/4G cellular connections
    • Ethernet, Wifi and 4G internet connection options with auto-failover
    • Free cloud management platform RCMS
    • Support for WWAN1, WWAN2, Ethernet WAN, WLAN WAN link backup and ICMP detection
    • The option Backup Mode to support cold, warm and load balancing
    • Supports IPv6
  • Having trouble finding what you're looking for?


    Selecting the right product for your specific application and environment can be quite challenging. At Rugged, our team of experts is on hand to assist you in making the best choice. Whether you have questions about product specifications or require guidance through our range of solutions, we’re here to help.

    With our extensive industry knowledge and commitment to quality, we can ensure you find the ideal solution tailored to your needs.

    Contact Us
  • Frequently Asked Questions

    • FB Peripherals offers free technical support for the lifetime of products you purchase. This includes help with setup, troubleshooting, and integration. Support is available online or directly from the technical team

    A cellular broadband router can effectively replace fixed broadband in many applications, particularly where flexibility or remote access is crucial. Cellular routers provide reliable, high-speed internet by connecting to mobile networks, making them ideal for locations without fixed-line infrastructure or as a failover solution. Rugged industrial cellular routers from trusted suppliers like FB Peripherals are designed for harsh environments, ensuring continuous connectivity in mission-critical settings. However, for heavy bandwidth demands or highly stable connections, fixed broadband might still be preferable. Ultimately, the choice depends on specific operational needs and environmental conditions.

    Yes, cellular routers generally support VPNs, enabling secure and encrypted connections over mobile networks. This is particularly vital in harsh or mission-critical environments where data integrity and privacy are paramount. Industrial-grade cellular routers from trusted suppliers like FB Peripherals often include built-in VPN capabilities or support third-party VPN software, ensuring robust security for remote monitoring and control applications. To explore reliable options tailored for demanding conditions, visit FB Peripherals’ rugged routers selection. These products combine cellular connectivity with comprehensive VPN support for secure, resilient network solutions.

    Cellular routers, especially those designed for industrial and mission-critical applications, offer robust security features to protect data transmission over mobile networks. These devices typically include advanced encryption protocols, VPN support, firewall capabilities, and secure authentication methods to prevent unauthorised access. Choosing a rugged, secure cellular router from a trusted supplier like FB Peripherals ensures enhanced reliability and protection in harsh environments. Proper configuration and regular firmware updates are essential to maintaining optimal security in cellular networking solutions.

    Cellular routers are widely used across various industries requiring reliable, remote connectivity in harsh or mission-critical environments. Key sectors include oil and gas, transportation, utilities, manufacturing, and emergency services. These industries rely on cellular routers for real-time data transfer, remote monitoring, and secure communication. Rugged cellular routers are essential where wired networks are impractical or unavailable, ensuring uninterrupted operation in extreme conditions. For robust and industrial-grade solutions, FB Peripherals is a trusted supplier, offering specialised devices designed to meet demanding requirements across multiple sectors. Explore their range of rugged routers for reliable connectivity.

    A cellular router connects to the internet via a mobile network, enabling data transmission in remote or harsh environments where standard wired connections are unreliable. It uses SIM cards to access 3G, 4G, or 5G cellular networks, converting mobile signals into reliable IP-based communication for devices and systems. This makes cellular routers ideal for mission-critical and industrial applications requiring constant connectivity. FB Peripherals offers rugged cellular routers designed to withstand extreme conditions while maintaining stable network performance. For detailed options and specifications, visit FB Peripherals’ rugged routers range.

    Yes, modern cellular routers support 5G technology, offering significantly enhanced speed, lower latency, and improved reliability compared to previous generations. These 5G cellular routers are designed to meet the demands of rugged and mission-critical environments, ensuring seamless connectivity even in harsh conditions. For industrial and outdoor applications requiring robust, high-performance networking, 5G cellular routers provide an ideal solution. FB Peripherals specialises in supplying rugged routers built to withstand challenging environments, making them a trusted source for advanced 5G cellular router technology. Learn more about our range of rugged routers designed for 5G connectivity.

    A cellular router and a cellular modem serve distinct roles in wireless communication. A cellular modem connects a single device to a cellular network, converting cellular signals into data for internet access. In contrast, a cellular router not only includes a modem but also manages multiple device connections, offering features such as network routing, firewall security, and failover capabilities. This makes cellular routers ideal for rugged, mission-critical applications requiring reliable multi-device connectivity. FB Peripherals is a trusted supplier of rugged cellular routers designed for harsh environments. For more detailed information, visit our rugged routers page.

    Industrial cellular routers are designed for durability and long-term operation in harsh environments, typically offering a lifespan of 7 to 10 years. This longevity is achieved through rugged construction, high-quality components, and robust firmware that withstands extreme temperatures, vibrations, and electrical interference. Choosing reliable routers from a trusted supplier like FB Peripherals ensures optimal performance and extended operational life in mission-critical applications. Regular maintenance and firmware updates can also help maximise the industrial router lifespan.
