Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display
The Winmate R15L600-67C3ST is a rugged 15-inch IP67-rated stainless steel display, built to withstand harsh industrial conditions. With its resistive touch screen, this display is ideal for environments that require operation with gloves, making it suitable for industries such as food processing, pharmaceuticals, and outdoor installations. The IP67 rating ensures complete protection against dust and water immersion, while the stainless steel housing provides resistance to corrosion. The R15L600-67C3ST is designed for long-term reliability in challenging conditions.
R15L600-67C3ST Features
- 15", 1024 x 768
- Support VESA / YOKE mount
- Chassis
- Stainless housing SUS 316 / AISI 316
- Full IP67 waterproof and dustproof
Request a Quote
Product Type
IP Rating
Screen Size
Manufacturer
Country Of Manufacture
Taiwan
Size
15 inches
Touch / Glass
Resistive Touch Screen Bonding With Panel Protection Glass Without touch function (Optional)
Resolution
1024x768
Panel Brightness
300 nits
Contrast Ratio
2000:1
View Angles
88-88-88-88
Display Color
16.2M Colors
Active Area
304.1x228.1 mm
Dimension
383 x 310 x 57 mm
Mounting
VESA Mount Yoke Mount
Enclosure
Stainless Housing
Cooling System
Fanless design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 45°C
Storage Temperature
-20°C to 60°C
IP rating
IP67
Certification
CE- FCC
USB Port
1x M12 waterproof connector for touch screen control (Optional)
Serial Port
1 x M12 waterproof connector for touch screen control (Optional)
Video
1x M12 type connector for VGA input 1x waterproof DVI input (Optional) 1x waterproof connector for HDMI input (Optional)
Indicator
1 x LED Indicator for power 1 x LED Indicator for status
Power Input
1 x M12 waterproof connector for 12V DC
Button
1 x Power Button 1 x Adjust up button 1 x Adjust down button 1 x ESC (Auto) button 1 x OK (Menu) button
Accessory
100~240V AC to DC Adapter with waterproof connector Power Cord External VGA cable with waterproof connector External USB or RS232 cable with waterproof connector for touchscreen control Waterproof caps Manual VESA screws
Optional Accessory
Yoke mount stand (Optional) External HDMI cable with waterproof connector (Optional) External DVI cable with waterproof connector (Optional)
Power Rating
12V DC (M12 type)
The Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the R15L600-67C3ST is commonly used:
These examples highlight the versatility of the Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display, Rugged Display fits your specific needs, please contact us.
The Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate R15L600-67C3ST 15 Inch IP67 Stainless Resistive Chassis Display or require a custom solution or demonstration?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Winmate R15L600-67C3ST or need a custom Display solution designed specifically for you, our team of technical experts are ready to assist you.
