Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC
The Winmate W04FA3S-ELT1 is a compact 4.3-inch HMI panel PC powered by the NXP i.MX6 processor, designed for applications where space is limited but durability and performance are required. As part of the EL Series, this panel PC is built for embedded systems, automation, and control applications. The small form factor makes it ideal for tight installations, while the responsive touchscreen allows for easy operation. Despite its compact size, the W04FA3S-ELT1 offers rugged construction, ensuring reliable performance in industrial environments.
W04FA3S-ELT1 Features
- 4.3” 480 x 272 Resolution with P-Cap Multi-touch screen
- NXP i.MX6 Dual Core 1GHz
- Fanless cooling system and Ultra-low power consumption
- Front IP65 Water and Dust Proof
- 1 x USB , 1 x USB OTG , 1 x RS485 , 1 x RJ45 / LAN
Request a Quote
Product Type
IP Rating
Screen Size
Manufacturer
Country Of Manufacture
Taiwan
Size
4.3 inches
Touch / Glass
Projected Capacitive Multi Touch Screen
Resolution
480x272
Panel Brightness
400.0 nits
Contrast Ratio
900:1
View Angles
80-60-80-80
Active Area
95.040x53.856 mm
Processor
NXP i.MX6 Dual Core- 1.0GHz
Memory
1GB 2GB (Optional)
Storage
eMMC: Onboard 8 GB
Operating System
Linux Ubuntu 18.04 (Optional) Android 6.0 (Optional) Debian 7.0 (Optional) Linux 4.1.15 QT 5.5 (Optional)
Dimension
121 x 82 x 49 mm
Cut out
109.6 x 71.2 mm
Weight
0.3 kg
Mounting
Panel mount
Enclosure
Metal Housing
Cooling System
Fanless design
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
USB Port
1 x USB2.0 (Type-A) 1 x USB OTG
Serial Port
1 x RS485- 3pin Terminal block
LAN
1 x LAN RJ45 Connector
Indicator
1 x LED Indicator for storage
Power Input
1 x 12~24V DC- 3-Pin Terminal Block
Button
1 x Reset Button
Accessory
100~240V AC to DC Adapter Power Cord Terminal Block to 2.5Ø Female Adapter Cable Open Wire Cable with terminal block connector Mounting clips VESA screws
Power Rating
12V~24V with isolation- 3-Pin Terminal Block
Adapter
12V 50W
The Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the W04FA3S-ELT1 is commonly used:
These examples highlight the versatility of the Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Panel PC, Rugged Panel PC fits your specific needs, please contact us.
The Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate W04FA3S-ELT1 4.3 Inch EL Series HMI Panel PC or require a custom solution or demonstration?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Winmate W04FA3S-ELT1 or need a custom Panel PC solution designed specifically for you, our team of technical experts are ready to assist you.
