iKey IK-TR-88-911 Rugged Keyboard

This brand new Transformer Keyboard from iKey has been designed with active service in mind—to be an ideal on-the-go solution for in-vehicle use by the emergency services. Devised with the keywords ‘flexibility’ and ‘versatility’ foremost, the IK-TR-88-911-TP offers a host of features that can accommodate a wide range of uses in the field.

To keep things simple, however, and to facilitate an easy introduction of the new keyboard, it has been designed to fit into existing mobile mounting systems—but its range of functions and options gives it the edge over alternative models. With its built-in high-speed USB hubs and modular options, this keyboard can be used for multiple configurations in the field and on the road—and its versatility is one of its key selling points.

The compact keyboard that’s fully loaded

The IK-TR-88-911-TP packs a full raft of functions and features into its diminutive case. It has 88-key functionality with 12 dedicated function keys, plus an integrated touchpad and a one-touch emergency key. To facilitate use in poor conditions, the keys are backlit and the rugged case is fully sealed, making it 100% humidity proof. The keypads are made of industrial silicone rubber, with tactile mechanical snap key switches. It is resistant to dirt, dust and moisture and it operates within a temperature range of -20C to +60C. Mobile mounting holes make installation into vehicles easy and it weighs less than a kilo, making it fully portable.

Versatility in the field

The new IK-TR-88-911-TP offers unprecedented flexibility of use and can withstand tough conditions on the road. It can be used on its own or mounted in a vehicle and it represents an excellent solution for military, emergency services, medical, industrial and energy industry applications.



IK-TR-88-911-TP

A compact mobile keyboard that’s big on functionality

IK-TR-88-911 Features

  • 88-Key Functionality
  • Integrated LED Backlighting
  • Integrated Touchpad
  • 12 Function Keys
  • Various Keyboard and Language Layout Options
  • Customisation Available On Request

Request a Quote

Manufacturer

Country Of Manufacture

United States

Backlight

Red

Case Material

ABS Polycarbonate

Certifications

CE, RoHS compliant

Custom Options Products

Keyboard Layout,Keyboard Language,Cable Type,Cable Length,Interface

Dimensions

302.77 x 194.3 x 31.24 mm (11.92 x 7.65 x 1.23 inches)

Housing Colour

Black

Humidity

100% Humidity Resistant

Compatibility

All Windows Operating Systems

Flammability

PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94HB INTERFACE CABLE: 94 VO

Function Keys

12 Keys

Key Feedback

Mechanical

Key Material

ABS Plastic

Lifespan

>10 Million Actuations

No. Of Keys

88

Pointing Device

Touchpad

Power

USB: 35mA@5V (from CPU port)

Product Weight

2.0 lbs +/- 0.10 lbs (0.90 kg +/- 0.05 kg)

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Shock

3 x 11 ms Pulses of 50g on each of 3 Axes

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)

The iKey IK-TR-88-911 Rugged Keyboard is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the IK-TR-88-911 is commonly used:

Industrial and Manufacturing, Outdoor and Mobile Computing, Public Safety and Emergency Services, Transport and Logistics

These examples highlight the versatility of the iKey IK-TR-88-911 Rugged Keyboard across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Keyboard, Rugged Keyboard fits your specific needs, please contact us.

The iKey IK-TR-88-911 Rugged Keyboard comes with a 1 Year Limited Warranty against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).

To receive service under this warranty, the eligible product, iKey IK-TR-88-911 Rugged Keyboard, must be presented to RUGGED in the United Kingdom.

For more information about the iKey IK-TR-88-911 Rugged Keyboard or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.

Do you need further details about the iKey IK-TR-88-911 Rugged Keyboard or require a custom solution or demonstration?

At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the iKey IK-TR-88-911 or need a custom Keyboard solution designed specifically for you, our team of technical experts are ready to assist you.
