Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display
The Winmate W15L100-PPB2 is a 14.9-inch multi-touch panel mount display designed for industrial and commercial applications that require a robust and reliable touch interface. Featuring projected capacitive (PCAP) multi-touch technology, this display delivers smooth and responsive touch performance, making it suitable for interactive systems and control applications. The panel mount design ensures easy integration into kiosks, automation systems, and industrial machinery. With its durable construction and versatile functionality, the W15L100-PPB2 is a reliable solution for demanding environments.
W15L100-PPB2 Features
- 14.9” 1920 x 720 Resolution
- VGA input and HDMI input
- Panel mount
- Projected Capacitive Multi-Touch
- Front IP65
Request a Quote
Product Type
Format
IP Rating
Screen Size
Manufacturer
Country Of Manufacture
Taiwan
Size
14.9 inches
Type
Projected Capacitive Multi Touch
Resolution
1920x720
Panel Brightness
950.0 nits
Contrast Ratio
1000:1
View Angles
85-85-85-85
Display Color
16.7M Colors
Active Area
355.68×133.38 mm
Operating Humidity
10% to 90% RH- Non Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE- FCC
USB Port
1 x USB for Touch Screen
Video
1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional)
Audio
Audio line in (3.5mm) (Optional) 2 x Speaker (Optional)
Dimension
400 x 187.6 x 59 mm
Cut out
378.1 x 164.6 mm
Weight
5.5 kg
Mounting
Panel Mount
Enclosure
Metal Housing with Aluminum Bezel
Cooling System
Fanless Design
Accessory
1 x VGA cable 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product)
Optional Accessory
Remote Controller (Optional-Varies by product)
Power Rating
12V DC in 24V DC in (optional)
Button
5 Keys: - - + - Power - Esc - Enter
The Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display is designed to meet the demands of various markets that require rugged, reliable products. Below are some of the key industries where the W15L100-PPB2 is commonly used:
These examples highlight the versatility of the Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display across a range of market applications, with its potential extending far beyond the sectors listed here. For more information or to assess if this Display, Rugged Display fits your specific needs, please contact us.
The Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display comes with a 1 Year RTB UK Warranty With Option To Extend upto 3 Years against defects in workmanship and materials, effective from the date of shipment (unless otherwise agreed in writing).
To receive service under this warranty, the eligible product, Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display, must be presented to RUGGED in the United Kingdom.
For more information about the Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display or to arrange repairs and services not covered by the warranty, please visit the warranty section on our website.
Do you need further details about the Winmate W15L100-PPB2 14.9 Inch Multi-Touch Panel Mount Display or require a custom solution or demonstration?
At FB Peripherals, we recognise that every project has its own unique demands. If you have any questions about the Winmate W15L100-PPB2 or need a custom Display solution designed specifically for you, our team of technical experts are ready to assist you.
